Dryburgh Abbey

A ruined arcade in trees

Dryburgh Abbey on the Tweed, where Walter Scott is buried: Forrest's plate (21.5 by 26 centimetres) shows a ruined range of pointed arches with a broken skyline, dense foliage pressing in from the right, lawn in front. It is the capstone subject of this course in a Forrest plate: Gothic arches constructed true, a skyline drawn as negative shapes, masonry suggested, and trees as masses softening the whole.

Difficulty
Time
about 3.5 h
You draw with
H, HB, 2B, 4B, 6B graphite
The ruin's silhouetteConstructing a pointed archAn arch in perspectiveMasonry coursingBuilding a tree from massesCast shadows on buildings

Why this one

  • Pointed arches in perspective, a broken skyline, suggested coursing, and foliage masses on one plate.
  • The direct ancestor of the course capstone: architecture inside air.

From your kit

The whole kit →
  1. 1Grafwood H, HB, 2B, 4B, 6B H, HB for layout and line; 2B, 4B, 6B for the darks. Long points from the Blackwing on everything up to B.
  2. 2Kneaded eraser and the Mono Zero press-and-lift corrections only; the Mono Zero for a single sharp light.
  3. 3Alpha sketchbook 9 x 6 draw at the book's size and keep the proportions; date the page.
In general, this study asks for
  • Drawing pad or smooth cartridge
  • 2H and H with long points
  • HB for accents
  • Kneaded eraser
  • Sandpaper block
  • 2B, 4B, 6B

Watch first

All videos →

Timothy Wilcox on the Normandy tours and the Architectural Antiquities etchings. The architectural half of this course, explained by its curator.

YouTube
How to sketch buildings and architecture: Greek ruinsPhil Davies Artist · A ruin blocked in from the envelope. Ink and wash, but the construction is identical in pencil.Gothic archesTech Drawing for Carpentry and Joinery · Equilateral, lancet and drop arches constructed properly with a compass.Architectural pencil drawing tutorialMinty Sainsbury · Structure first, then tone, on a real stone building. The method of the Architecture studies in a modern hand.Medieval math: how to create a Gothic arch with a stringMedieval DIY · How the masons did it on site, which is how you do it in the field with a pencil.

The plan

4 stages · ~210 min
  1. 1

    Envelope and skyline

    30 min

    Envelope the ruin as one mass. Draw its skyline as sky shapes, slowly. Then the big planes.

    A ruined abbey wall read as silhouette: one big stable mass, an irregular broken skyline, dark window voids, and vegetation softening the lower edgebrokenskylinegrowthsky behindwall behindA ruin is one mass with its top bitten off. Some voids show sky, some show darkwall. Never all the same.Cotman's Normandy castle, Prout's Norham, Forrest's Dryburgh: the skyline does the storytelling.
    FigureStable mass, broken skyline.
    Checklist0 / 1
  2. 2

    Arches constructed

    50 min

    Each arch in its perspective opening: springing points, apex height sighted, two arcs. Voids decided: sky or wall behind.

    Constructing an equilateral pointed arch: two arcs, each with its centre at the opposite springing point and a radius equal to the span, meeting at the apex; plus lancet and drop variantsEQUILATERAL ARCH · RADIUS = SPANspringing linecentre Bcentre Aapexr = spanVARIANTSlancet: r >spandrop: r <spanCompass on paper, thumb-and-pencil in the field. Mark the two centres, swing twoarcs, done.Melrose, Dryburgh, Rievaulx: once you can strike this arch you can draw any abbey in Britain.
    FigureTwo centres, two arcs.
    Checklist0 / 2
  3. 3

    Masonry and tone

    70 min

    Courses as broken lines; stones at edges and openings. Shadow planes in two layers, voids three to four. Cast shadow on the lawn at one angle.

    Checklist0 / 2
  4. 4

    Trees and audit

    60 min

    Foliage mass with the side of the 4B, soft against the stone, lit on top, texture at its edge only. Squint: ruin inside air? Box.

    Checklist0 / 2

What it should look like

  • A ruin whose arches are true and whose skyline tells the story, held inside a mass of trees.

Where it goes wrong

  • Foliage drawn as hard-edged as the stone. Same pencil, same pressure. Side of the 4B for the trees; soften the edge where they meet the ruin.
